SCT 5015P LIVEWIRE TS+ PERFORMANCE PROGRAMMER

Description

The SCT 5015P Livewire TS+ Performance Programmer is a performance upgrade and monitor all in one for your 1999-2015 Ford Powerstroke. From the factory, your vehicle’s computer is calibrated for the masses, designed with the average driver in mind, not the performance enthusiast. This not only leaves valuable Horsepower & Torque hidden inside your vehicle, but it also makes for a mediocre driving experience. The Livewire TS unlocks your vehicle’s hidden performance by re-calibrating your vehicle’s computer for Maximum Horsepower & Torque, Increased Throttle Response, Firmer Shifts and even Increased Fuel Mileage.

SCT’s Pre-loaded Dyno Proven tune files optimize the vehicle’s Air / Fuel Ratio, Engine Timing & Fuel Curves for Maximum Performance while maintaining the factory reliability & drivability. Whether towing a fully loaded car trailer or a 5th Wheel Camper, SCT’s Towing tune files add the perfect mix of Horsepower & Torque to help make hauling loads easier. SCT’s Performance & Towing tune files not only optimize the vehicle for Maximum Performance, they often INCREASE the vehicle’s FUEL MILEAGE by up to 1-2MPG!

Features:
Full Color 4″ Touch Screen Display
Rear View Camera Input
Pre-Loaded Dyno Proven Tunes
Stores Up To 10 Custom Tunes
High Speed Data Loggin – Monitoring
Built-In Performance Calculator
Read & Clear DTC Trouble Codes
Improved User Interface For Easier Navigation
User Adjustable Themes & Tune Options
Built-In Wifi For Easy Wireless Updates
Rear Exit Cable Connection For Easier, Cleaner Device Mounting.
Shift On-The-Fly Power Level Adjustments (Select Powerstroke Applications)*
Livewire TS+ Includes:

Livewire TS+ Performance Tuner & Monitor
OBDII Cable w/ Video & Analog Input
High Speed Mini USB Cable
Livewire TS Suction Cup Windshield Mount
SCT Chrome Badge
Applications:
1999-2003 F-Series Super Duty 7.3L: +110HP & +200ft-lbs.
2003-2007 F-Series Super Duty 6.0L: +120HP & +248ft-lbs.
2008-2010 F-Series Super Duty 6.4L: +113HP & +141ft-lbs.
2011-2012 F-Series Super Duty 6.7L: +88HP & +101ft-lbs.
2013-2015 F-Series Super Duty 6.7L: +135HP & 151ft-lbs.

5015P Livewire TS+ PID’s Monitored

6.7L Powerstroke
7.3L/6.0L Powerstroke
6.4L Powerstroke
ABSOLUTE LOAD IN PERCENT
ACCEL PEDAL POSITION D
ACCEL PEDAL POSITION E
ACCEL PEDAL POSITION VOLTS
AMBIENT AIR TEMP C
AMBIENT AIR TEMP F
AVERAGE DISTANCE BETWEEN REGEN
BAROMETRIC PRESSURE
BATTERY VOLTAGE
DISTANCE SINCE DTC CLEARED KM
DISTANCE SINCE DTC CLEARED MILE
DISTANCE SINCE LAST REGEN
DPF SOOT MASS
DTC COUNT
DTC COUNT TCM
ENGINE COOLANT TEMP C
ENGINE COOLANT TEMP F
ENGINE OIL TEMP
FUEL LEVEL SENSOR
FUEL RATE
GEAR COMMANDED
INTAKE AIR TEMP VOLTS
MAF FREQUENCY
MAP ABSOLUTE KPA
REDUCTANT LINE PRESSURE
REDUCTANT UREA LEVEL
RPM
RUN TIME
TCC SOLENOID PRESSURE KPA TCM
TRANS FLUID TEMP F TCM
TURBO BOOST
VEHICLE SPEED MPH TCM

ACCEL PEDAL POSITION
AIR FLOW #/MIN
BAROMETRIC PRESSURE IN HG
BATTERY VOLTAGE
COMMANDED GEAR
COOLANT TEMP
ENGINE OIL TEMP F
INJECTION CONTROL PRESSURE
INJECTOR PULSE WIDTH
INTAKE AIR TEMP
LOAD
TURBO BOOST
MAP
RPM
TORQUE CONVERTER CLUTCH DUTY CYCLE
TRANS TEMP
VEHICLE SPEED
VGT DUTY CYCLE
FICM_IGNITION
FICM_LOGIC_POWER
FICM_MAIN_INTERNAL_INJECTOR_PWR

BAROMETRIC PRESSURE KPA
BATTERY VOLTAGE
COOLANT TEMP
DPF REGEN STATUS
EGT
ENGINE LOAD
ENGINE OIL TEMP
INTAKE AIR TEMP
MAF
PEDAL POSITION
RPM
SECONDARY EGT
TRANS TEMP TCM
TURBO BOOST
VEHICLE SPEED

Note: SCT 9817 EGT Kit is required to read exhaust gas temperatures. (Not included)
